Wing P Series Boats
- Wing hull design creates hydrodynamic lift and compartmentalizes the running surface to reduce vacuum - quicker to plane and greater speeds with heavier loads
- Large interior space
- Polyurethane Fabric used throughout for longer life and 2-3 times the puncture resistance of Hypalon or PVC
- Thermo welded seams for a joint as strong as continuous material
- Composite transom; lighter weight and stronger than aluminum, will not decay like wood
- California made with U.S. materials and Berry Amendment compliant
Combat Rubber Raiding Craft
Made of Cooley Coolthane® polyurethane fabric, the P Series is stronger and enjoys 2-3 times the puncture resistance of Hypalon and PVC products. Tube seams are heat welded into a single fabric – not glued – forming a joint even stronger than the material itself.
In speed tests with medium loads, each of the P Series boats without speed tubes achieved the same top-end speed as a competitive model with speed tubes. Additionally, each of the P Series throw a smaller wake profile — so clandestine operations stay that way.
As an example: Under light load conditions of 800lbs with a 40hp engine, the P4.7 exceeds 30 miles per hour. It also features 20% more usable deck space than similar-sized competitive models and is nearly 50 lbs. lighter.
- Hull design creates hydrodynamic lift and compartmentalizes the running surface to reduce vacuum — affording higher running surface to reduce vacuum — affording higher speeds with heavier loads, quicker to plane and greater fuel speeds with heavier loads, quicker to plane and greater fuel efficiency
- The design of Wing CRRCs without speed tubes out-performs the competition’s boats with speed tubes in a medium load.
- Interior space of the Wing P-Series is greater than the competitive respective models.
- Independent tests prove Polyurethane fabric makes a stronger, more durable tube with better air-holding characteristics than Hypalon or PVC alternatives, contributing to superior performance in all conditions.
- Thermal welded seam failure is virtually non-existent. Count on extended service life thanks to virtually no maintenance required on welded versus glued seams.
Specifications are estimates and are subject to varienace. More models to come!
| Model: | P4.2 Rescue | P4.2 | P4.7 | P5.3 | P5.8 |
| Overall Length: | 13'9"ft. 4.2m |
13'9"ft. 4.2m |
15'5"ft. 4.7m |
17'5"ft. 5.3m |
19'2"ft. 5.8m |
| Outside Beam: | 5'7"ft. 1.73m |
5'7"ft. 1.73m |
6'5"ft. 1.98m |
7'1"ft. 2.18m |
8'1"ft. 2.48m |
| Internal Length: | 10'9"ft. 3.27m |
10'9"ft. 3.27m |
12'3"ft. 3.73m |
13'2"ft. 4.01m |
13'9"ft. 4.2m |
| Internal Beam: | 2'6"ft. 0.81m |
2'6"ft. 0.81m |
3'ft. 0.91m |
3'4"ft. 1.04m |
4'ft. 1.22m |
| Tube Diameter: | 18"in. 45.7cm |
18"in. 45.cm |
20"in. 50.8cm |
22"in. 55.9cm |
25"in. 63.5cm |
| Number of Chambers: | 3 | 3 | 5 | 5 | 5 |
| Usable Deck Space: | 27.0ft² 2.84m² |
27.0ft² 2.84m² |
38.32ft² 3.56m² |
44.78ft² 4.169m² |
54.89ft² 5.1m² |
| Min Floor Length: | 10'8"ft. 3.28m |
10'8"ft. 3.28m |
12'2"ft. 3.73m |
13'1"ft. 4.019m |
13'8"ft. 4.229m |
| Craft Weight Empty: | 130lbs. 59kgm |
150lbs. 68kg |
180lbs. 81.1kg |
192lbs. 87.3kg |
275lbs. 125kg |
| Weight w/ High Pressure Air Deck: | 170lbs. 77.3kg |
187lbs. 85kg |
N/A | N/A | N/A |
| Weight w/ Composite Hard Deck: | 223lbs. 101.3kg |
240lbs. 109kg |
279lbs. 126.8kg |
312lbs. 141.8kg |
459lbs. 208.6kg |
| Weight w/ Composite Roll Up Deck: | 198lbs. 90kg |
215lbs. 97.7kg |
274lbs. 124.5kg |
302lbs. 137.3kg |
N/A |
| Folded Dimensions: | 23" x 23" x 50" 63.5 x 74 x 122cm |
25" x 25" x 52" 63.5 x 63.5 x 132cm |
27" x 29" x 56" 68.6 x 74 x 142cm |
38" x 38" x 65" 96.5 x 96.5 x 165cm |
36" x 36" x 81" 91.4 x 91.4 x 205.7cm |
| Transom Height: | 20"in. 50.8cm |
20"in. 50.8cm |
20"in. 50.8cm |
20"in. 50.8cm |
20"in. 50.8cm |
| Max Payload: | 2,099lbs. 952kg |
2,099lbs. 952kg |
2,768lbs. 1,251kg |
3,999lbs. 1,814kg |
5,999lbs. 2,721kg |
| Person Capacity: | 8 | 8 | 10 | 12 | 15 |
| Max HP Rating (Hard Deck/Roll Deck): |
50/30 | 50/30 | 65/65 | 80/70 | 115 Hard Deck Only |
| Max Engine Weight: | 242lbs. 110kg |
255lbs. 115.9kg |
320lbs. 145.5kg |
345lbs. 156.8kg |
420lbs. 190.9kg |
| Standard Color: | Red or Black | Black | Black | Black | Black |
- D-rings for towing bridle
- Deck drain, high capacity
- External/Internal lifelines
- Handles, 6 ea. side, one bow
- Keel, inflatable with valve
- Lifting rings (4)
- Rub strakes on sides and keel
- Composite transom, floorboards, and thrustboard — lighter and stronger than aluminum and impervious to detrioriation from water intrusion (won’t rot like wood)
- Transom tow eyes
- Auto-inflation
- Multi-piece composite forward for more storage
- Equipment bags
- Dull Coat
- 6, 9, and 18 gallon collapsible fuel bags
- Roll-up lightweight composite deck
- Fleet customization: For multiple boat orders watchers, shark fishermen, dive teams, and arctic explorers out there
